Informații suplimentare
| Greutate | 2,7 kg |
|---|---|
| Dimensiuni | 40 × 9 × 32 cm |
| Forwarding rate | 14.88 Mpps |
| LED indicators | Activity, Link, Power, Speed |
| Compliance certificates | BSMI, CB, CCC, cUL |
| Certification | CE A, VCCI A, FCC A, BSMI, CCC |
| Jumbo frames | 10000 |
| Number of static routes | 256 |
| Packet buffer memory | 4.1 MB |
| Store-and-forward | Yes |
| Switching capacity | 20 Gbit/s |
| MAC address table | 8000 entries |
| Jumbo frames support | Yes |
| Static route | Yes |
| Product colour | Black |
| Safety | CB, UL, BSMI, CCC |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Flow control support | Yes |
| Flash memory | 32 MB |
| Mean time between failures (MTBF) | 1274005 h |
| Noise level | 0 dB |
| Harmonized System (HS) code | 85176990 |
| Switch layer | L2/L3 |
| ARP inspection | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Switch type | Managed |
| Firmware upgradeable | Yes |
| Multicast support | Yes |
| Head-of-line (HOL) blocking | Yes |
| Number of VLANs | 4094 |
| Cable types supported | Cat5, Cat5e |
| Auto MDI/MDI-X | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| 10G support | No |
| Half duplex | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Port mirroring | Yes |
| Full duplex | Yes |
| Power over Ethernet (PoE) | Yes |
| Link aggregation | Yes |
| Security algorithms | 802.1x RADIUS, EAP, MD5, PEAP, SNMP, SSH-2, SSL/TLS, TTLS |
| Heat dissipation | 519.51 BTU/h |
| Operating temperature (T-T) | -5 – 50 °C |
| Storage temperature (T-T) | -20 – 70 °C |
| Operating relative humidity (H-H) | 0 – 95% |
| Storage relative humidity (H-H) | 0 – 95% |
| Fiber ethernet cabling technology | 100BASE-FX, 1000BASE-X |
| Package depth | 400 mm |
| Package height | 91 mm |
| Package width | 319 mm |
| Package weight | 31 kg |
| Maximum cable length | 100 m |
| Memory type | DDR3-SDRAM |
| SFP module slots quantity | 2 |
| Installed SFP modules quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Fiber optic connector | SFP |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power supply included | Yes |
| Number of power supply units | 1 |
| Power consumption (max) | 152.3 W |
| Power source | AC |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Total Power over Ethernet (PoE) budget | 130 W |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Access Control List (ACL) | Yes |
| IP-MAC-Port binding | Yes |
| IGMP snooping | Yes |
| Loop protection | Yes |
| DHCP features | DHCP server, DHCP client |
| Access Control List (ACL) rules | 768 |
| Sustainability compliance | Yes |
| Products per shipping (inner) case | 3 pc(s) |
| Products per pallet (air) | 72 pc(s) |
| Products per pallet (sea) | 120 pc(s) |
| Shipping (inner) case height | 34.9 cm |
| Shipping (inner) case width | 29.4 cm |
| Shipping (inner) case length | 41.6 cm |
| Shipping (inner) case net weight | 9.31 kg |
| Pallet gross weight (air) | 268.3 kg |
| Pallet height (air) | 118.2 cm |
| Pallet gross weight (sea) | 430.6 kg |
| Pallet height (sea) | 188 cm |
| Shipping (inner) case gross weight | 10.1 kg |
| Master (outer) cases per pallet (air) | 24 pc(s) |
| Master (outer) cases per pallet (sea) | 40 pc(s) |
| Pallet gross length | 110 cm |
| Pallet gross width | 120 cm |
| Height | 44 mm |
| Width | 330 mm |
| Weight | 1.77 kg |
| Depth | 180 mm |
| LAN-Port-Type | Gigabit |
