Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 3
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 4
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 5
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 6
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 7
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 8
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 9
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 10
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 11
Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD - imagine 12

Sursa GIGABYTE UD1300GM PG5 80 PLUS GOLD

SKU: GP-UD1300GM PG5
Producator: Gigabyte
Disponibilitate:

27 în stoc
Add to wishlist
Compare

1.048,99lei 1.380,00lei

27 în stoc

Sursa GIGABYTE UD1300GM PG5, Active PFC (>0.9 typical), 1300W 80 PLUS GOLD, 140mm double ball bearing fan

SKU: GP-UD1300GM PG5 Categorie:
PSU Type

ATX
Warranty period

5 year(s)
Depth

160 mm
Number of fans

1 fan(s)
Purpose

PC
AC input voltage

100 – 240 V
Illumination

No
Fan diameter

12 cm
Height

86 mm
Width

150 mm
Mean time between failures (MTBF)

100000 h
Conectivitate

Full – Modular
Iluminare RGB

Nu
Certificare 80 Plus

80 PLUS Gold
Motherboard power connector

20+4 pin ATX
CPU power connector (4+4 pin)

Yes
ATX power connector (20+4 pin)

Yes
PCI Express connector

Yes
Power supply unit (PSU) form factor

ATX
Fan location

Top
Max output current (+3.3V)

25 A
Max output current (+5V)

25 A
Number of SATA power connectors

8
Combined power (+5Vsb)

17.5 W
Max output current (+5Vsb)

3.5 A
Motherboard power cable length

61 cm
Cabling type

Fully-Modular
Power Factor Correction (PFC) type

Active
80 PLUS certification

80 PLUS Gold
Cable tie(s) included

Yes
Efficiency

90%
PCI Express power connectors (6+2 pin)

1
Peripheral (Molex) power connectors (4-pin)

2
PCI Express power cable length

70 cm
Hold time

16 ms
Power protection features

Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Combined power (+3.3V)

125 W
Combined power (+5V)

125 W
Input current

12 – 6 A
Number of PATA power connectors

3
Maximum input current (@110V)

6 A
Maximum input current (@220V)

12 A
Total power

1300 W
Combined power (+12V)

1300 W
Max output current (+12V)

108.3 A
SATA power cable length

150,600 mm
Peripheral (Molex) power cable length

200,600 mm
Cables included

CPU, PATA, Peripheral (Molex), SATA
Compliance certificates

CCC, CE, Federal Communications Commission (FCC), RoHS
PSU-Power

1300W
PFC

Active
Producator

GIGABYTE
Garantie

120
