Sursa MSI MPG A1000G PCIE5 80 PLUS GOLD

SKU: MPG A1000G PCIE5
Producator: Msi
Disponibilitate:

Stoc epuizat
Add to wishlist
Compare

1.386,99lei

Stoc epuizat

Sursa MSI MPG A1000G PCIE5 80+ GOLD Efficiency Rating 80 PLUS Gold (up to 90%) Modular Yes (fully modular) Fan Size 135 mm Fan Bearing Fluid Dynamic Bearing Dimensions (DxWxH) 150 x 150 x 86 mm PFC Type Active PFC Input Voltage Range 100~240 VAC Power Watt 1000W Power Excursion 2000W (*up to 200% of the PSU’s rated power for 100μs) Input Frequency Range 50~60 Hz Protection OCP / OVP / OPP / OTP / SCP / UVP ATX (24 pin) 1 EPS (4+4 pin) 2 PCI-E 5.0 (16 pin) 1 (600W) PCI-E (6+2 pin) 6 SATA (15 pin) 12 MOLEX (4 pin) 4 FDD (4 pin) 1

SKU: MPG A1000G PCIE5 Categorie:
PSU Type

ATX
Number of fans

1 fan(s)
AC input voltage

100 – 240 V
Illumination

No
Height

86 mm
Peripheral (Molex) power connectors (4-pin)

4
Width

150 mm
Depth

150 mm
Purpose

PC/Server
Conectivitate

Full – Modular
Iluminare RGB

Nu
Certificare 80 Plus

80 PLUS Gold
Motherboard power connector

20+4 pin ATX
EPS power connector (4+4 pin)

Yes
Power supply unit (PSU) form factor

ATX
Combined power (+5Vsb)

15 W
Max output current (+5Vsb)

3 A
Motherboard power cable length

60 cm
Cabling type

Fully-Modular
ATX version

3.0
Power Factor Correction (PFC) type

Active
Floppy disk drive connector

Yes
80 PLUS certification

80 PLUS Gold
Bearing technology

FDB
Efficiency

90%
Number of SATA power connectors

12
PCI Express power cable length

75 cm
EPS power connector (8-pin)

No
Fan diameter

13.5 cm
Power protection features

Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Combined power (+3.3V)

120 W
Combined power (+5V)

120 W
PCI Express power connectors (6+2 pin)

6
Max output current (+3.3V)

22 A
Max output current (+5V)

22 A
Total power

1000 W
Combined power (+12V)

1000 W
Max output current (+12V)

83.5 A
SATA power cable length

500,650,700,850 mm
Peripheral (Molex) power cable length

1100,500,650,700,850 mm
EPS cable length

70 cm
PSU-Power

1000 W
PFC

Active
Producator

MSI
Garantie

120
