Switch-uri
Switch Ubiquiti Gigabit EdgeSwitch ES-24-250W, 24 port, 10/100/1000 Mbps
Producator:
Ubiquiti
Disponibilitate:
Stoc epuizat
3.488,98lei
Stoc epuizat
| Numar porturi |
24x RJ-45
|
| Porturi |
24x RJ45
2x SFP |
| Viteza de transfer |
10/100/1000 Mbps
|
| Putere consumata |
250 W
|
| Alimentare |
100-240V AC
|
| PoE |
Da
|
| PoE Budget |
34.2 W
|
| Dimensiuni |
485 x 285.4 x 43.7 mm
|
| Greutate |
4.7 Kg
|
| Montare in rack |
1U
|
| Functii LED |
Serial / RJ45 / SFP
|
| Adrese MAC |
8K
|
| Metoda forwarding |
38.69 Mpps
|
| Routing/Switch Fabric |
52 Gbps
|
| Standarde |
IEEE802.3af, IEEE802.3at
|
| LAN-Port-Type | Gigabit |
|---|---|
| Management | Managed |
| PoE | Da |
| Operating relative humidity (H-H) | 5 – 95% |
| Product colour | Black |
| Jumbo frames support | Yes |
| Link aggregation | Yes |
| Power supply included | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Weight | 4.7 kg |
| Power consumption (max) | 250 W |
| AC input voltage | 100 – 240 V |
| Power over Ethernet (PoE) | Yes |
| Harmonized System (HS) code | 85176990 |
| Operating temperature (T-T) | -5 – 40 °C |
| Full duplex | Yes |
| Rack mounting | Yes |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Static route | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Switch type | Managed |
| Port mirroring | Yes |
| Form factor | 1U |
| MAC address filtering | Yes |
| Access Control List (ACL) | Yes |
| Height | 43.7 mm |
| Flow control support | Yes |
| Power over Ethernet (PoE) type supported | Active PoE, Passive PoE |
| IGMP snooping | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Installed SFP modules quantity | 0 |
| Switch layer | L2+/L3 |
| Configuring Location Settings (CLI) | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Console port | RJ-45 |
| 10G support | No |
| Half duplex | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Auto-sensing | Yes |
| Virtual LAN features | Private VLAN, Tagged VLAN, Voice VLAN |
| Number of VLANs | 4093 |
| MAC address table | 16384 entries |
| Switching capacity | 52 Gbit/s |
| Forwarding rate | 38.69 Mpps |
| Number of queues | 8 |
| DHCP features | DHCP server, DHCP snooping |
| Security algorithms | SSH-1.5, SSH-2, SSL/TLS |
| Authentication | Guest VLAN, Port-based authentication |
| Authentication type | IEEE 802.1x, RADIUS |
| Multicast support | Yes |
| Management protocols | SNMP v1/v2/v3, Telnet |
| LED indicators | Activity, Link, PoE, Speed |
| Power over Ethernet (PoE) power per port | 34.2 W |
| Width | 485 mm |
| Depth | 285.4 mm |
| Porturi RJ 45 | 24-28 |
| Viteza Transfer | Gigabit |
| Porturi SFP | 1-2 |
| Montare in Rack | Da |
| SFP module slots quantity | 2 |
| Certification | ETSI300-019-1.4 CE, FCC, IC |
| Producator | UBIQUITI |
| Garantie | 24 |
