Informații suplimentare
| Greutate | 6,9 kg |
|---|---|
| Dimensiuni | 53,5 × 10,5 × 44,5 cm |
| Console port | RJ-45/Micro-USB |
| Forwarding rate | 77.4 Mpps |
| LED indicators | Yes |
| Number of static routes | 48 |
| Store-and-forward | Yes |
| Packet buffer memory | 12 MB |
| Switching capacity | 104 Gbit/s |
| Jumbo frames | 9000 |
| MAC address table | 16000 entries |
| Jumbo frames support | Yes |
| Static route | Yes |
| Rack mounting | Yes |
| Form factor | 1U |
| Number of fans | 3 fan(s) |
| Reset button | Yes |
| Product colour | Black |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Quality of Service (QoS) support | Yes |
| Flow control support | Yes |
| VLAN support | Yes |
| Rate limiting | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3x |
| Harmonized System (HS) code | 85176990 |
| Cloud-managed | Yes |
| MIB support | Yes |
| Switch layer | L2/L3 |
| ARP inspection | Yes |
| Web-based management | Yes |
| System event log | Yes |
| Switch type | Managed |
| Multicast support | Yes |
| Active link detection | Yes |
| 10G support | No |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| IP routing | Yes |
| Number of VLANs | 4000 |
| Head-of-line (HOL) blocking | Yes |
| Power over Ethernet (PoE) | Yes |
| Link aggregation | Yes |
| Policy-based routing | Yes |
| Port mirroring | Yes |
| Virtual LAN features | MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 10 – 90% |
| Storage temperature (T-T) | -40 – 70 °C |
| Heat dissipation | 1656.19 BTU/h |
| Storage relative humidity (H-H) | 5 – 90% |
| Manual | Yes |
| Quick start guide | Yes |
| Cables included | AC |
| Package type | Box |
| Package height | 100 mm |
| Package width | 440 mm |
| Package depth | 528 mm |
| Package weight | 6.77 kg |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Power connector | AC-in jack |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Installed SFP+ modules quantity | 0 |
| SFP+ module slots quantity | 4 |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50/60 Hz |
| Power source | AC |
| Power consumption (max) | 485.4 W |
| Power supply included | Yes |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 384 W |
| Power over Ethernet plus (PoE+) ports quantity | 48 |
| Management protocols | SNMPv1/v2c/v3, SNTP |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| BPDU filtering/protection | Yes |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| Authentication | MAC-based authentication, Port-based authentication |
| SSH/SSL support | Yes |
| Loop protection | Yes |
| IGMP snooping | Yes |
| Password protection | Yes |
| Access Control List (ACL) | Yes |
| Depth | 330 mm |
| Height | 44 mm |
| Width | 440 mm |
| LAN-Port-Type | Gigabit |
