Informații suplimentare
| Greutate | 0,77 kg |
|---|---|
| Dimensiuni | 19,5 × 12 × 13,5 cm |
| Forwarding rate | 7.44 Mpps |
| LED indicators | Activity, Link, PoE, Power, Speed, Status |
| Certification | FCC, CE, RoHS |
| Packet buffer memory | 1 MB |
| MAC address table | 2000 entries |
| Number of queues | 4 |
| Store-and-forward | Yes |
| Switching capacity | 10 Gbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 16000 |
| Rack mounting | No |
| Product colour | Black |
| VLAN support | Yes |
| Quality of Service (QoS) support | Yes |
| Rate limiting | Yes |
| Flow control support | Yes |
| Harmonized System (HS) code | 85176990 |
| Switch layer | L2 |
| Web-based management | Yes |
| Switch type | Managed |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Power over Ethernet (PoE) | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| 10G support | No |
| Broadcast storm control | Yes |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e, Cat6 |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-FX, 100BASE-TX, 1000BASE-T |
| Virtual LAN features | Port-based VLAN, Tagged VLAN |
| Number of VLANs | 4000 |
| Heat dissipation | 256.3 BTU/h |
| Operating temperature (T-T) | 0 – 40 °C |
| Storage temperature (T-T) | -40 – 70 °C |
| Operating relative humidity (H-H) | 10 – 90% |
| Storage relative humidity (H-H) | 5 – 95% |
| User guide | Yes |
| Package depth | 196 mm |
| Package width | 131 mm |
| Package height | 121 mm |
| Package weight | 770 g |
| Fanless | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Installed SFP+ modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 5 |
| Power supply included | Yes |
| Power source | DC |
| Input voltage | 53.5 V |
| Input current | 1.31 A |
| Power consumption (max) | 75.16 W |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 65 W |
| Power over Ethernet (PoE) power per port | 30 W |
| IGMP snooping | Yes |
| Loop protection | Yes |
| Height | 25 mm |
| Depth | 98 mm |
| Width | 99.8 mm |
| LAN-Port-Type | Gigabit |
